| Engine |
Volvo D8M / D8J, 6‑cylinder turbocharged diesel |
| Gross/Net Power |
~272 hp (203 kW) at ~1,500 rpm |
| Max Torque |
~1,317‑1,320 Nm at ~1,450 rpm |
| Operating Weight |
~20,300‑20,600 kg (≈44,800‑45,600 lbs) |
| Bucket Capacity |
~3.3‑5.0 yd³ (~3.8 m³), up to 12.4 yd³ for special applications |
| Breakout Force |
~38,000‑41,000 lbs (≈170‑185 kN) |
| Static Tipping Load (Full Turn) |
~27,500 lbs (≈12,500 kg) |
| Dimensions (L×W×H) |
Length ~8.20‑8.35 m; Width ~2.67‑2.70 m; Height ~3.38 m |
| Ground Clearance |
~430‑440 mm |
| Transmission |
Powershift (Volvo HTL 206C) with OptiShift |
| Max Travel Speed |
~40 km/h |
